New series of wide band omnidirectional base station antennas for UHF band suitable for marine service too. The fiberglass protection radome and the anodized aluminium parts guarantee robustness and long life to all the SPO-antennas series. They are supplied with two strong extruded aluminium brackets and stainless steel hardware for a good installation on the mast.
Features:
Base station antenna, Wide-bandMedium-gain, OmnidirectionalSuitable for land and marine serviceProtection from static discharges DC-GroundPerfect protection against the worst weather conditionsDesigned to work without Ground PlaneStainless steel hardwaresElectrical Data
Type: ColinearFrequency range @ SWR ≤ 1.5:SPO-350-5: 350-400 MHzImpedance: 50ΩRadiation (H-plane): 360° omnidirectionalRadiation (E-plane): beamwidth @ -3 dB = 40°Radiation angle: 0°Polarization: linear verticalGain: 3 dBd - 5.15 dBiMax. power (CW) @ 30°C: 75 WattsGrounding protection: All metal part are DC-grounded, the inner conductor shows a DC-shortConnector: N-female with rubber protection capMechanical Data
Materials: White fiberglass radome Ø 28.6mm, anodized 6063-t5 aluminium, brass, stainless steel, copper, EPDM rubberWind load / resistance: 33 N @ 150 Km/h / 200 Km/hWind surface: 0.027 m²Height (approx.): 780 mmWeight (approx.): 890 grOperating temperature: -40°C to +80°CMounting mast: Ø 35-54 mm
