Base Station Antenna conceived for DECT system. The radiant element is a PTFE PCB to guarantee high power and low losses and it's protected by ASA radome. It's supplied with an aluminum bracket for an easy installation on the mcast. The antenna is made of 2 seperate sectors covering 180 degree each. When both sectors work in the same times they can cover 360 degree horizontal.
Features:
Base station multi sector antennaOmnidirectional coverage 2x180° horizontal beamwidthMono-band, High-gainDC-ground protectionMulti sector antenna made of PTFE PCB protected by grey thermoplastic UV stabilized radomeFor DECT systemElectrical Data
Type: Multi sector dipole arrayFrequency range: 1880-1980 MHz for DECT systemImpedance: 50ΩRadiation (H-plane): beamwidth @ -3 dB = 158° @ 1930 MHzRadiation (E-plane): beamwidth @ -3 dB = 27° @ 1930 MHzRadiation angle: 0°Front to back ratio: ≥ 10 dBIsolation: ≥ 30 dB (between any two port)Polarization: linear verticalGain: 6.5 dBd - 8.6 dBiSWR in bandwidth: ≤ 1.5:Max. power (CW) @ 30°C: 20 WattsGrounding protection: All metal part are DC-grounded, the inner conductor shows a DC-shortConnector: 2 x N-femaleMechanical Data
Housing materials: Aluminium, Stainless steel, PCBRadome material: Grey thermoplastic UV stabilizedWind load / resistance: 60 N @ 150 Km/h / 200 Km/hWind surface: 0.05 m²Height (approx.): 600 mmRadome diameter: Ø 136 mmWeight (approx.): 1150 grOperating temperature: -40° C to +80° CMounting mast: Ø 35-54 mm
